PlantUML

This Structurizr DSL plugin looks for inline PlantUML diagram definitions in Markdown/AsciiDoc documentation and decisions, and encodes them as images.

This plugin is available exclusively to Gold members of the Structurizr Patreon - an early access version is now available.

Markdown

This definition in Markdown content:

```plantuml
@startuml
Bob -> Alice : hello
@enduml
```

Will be converted to:

![](https://plantuml.com/plantuml/svg/SoWkIImgAStDuNBAJrBGjLDmpCbCJbMmKiX8pSd9vt98pKi1IW80)

Which renders as:

AsciiDoc

This definition in AsciiDoc content:

[plantuml]
....
@startuml
Bob -> Alice : hello
@enduml
....

Will be converted to:

image::http://plantuml.com/plantuml/svg/SoWkIImgAStDuNBAJrBGjLDmpCbCJbMmKiX8pSd9vt98pKi1IW80[]

Which renders as:

Usage

After installation, the plugin can be referenced from your DSL file as follows:

!plugin com.structurizr.dsl.plugin.documentation.PlantUML

This should appear after any !docs and/or !adrs statements that import documentation into your workspace.

You will need to provide a PlantUML URL, and optionally a format (png or svg), when using this plugin. These can be specified as view set properties:

views {
    properties {
        "plantuml.url" "http://localhost:8888"
        "plantuml.format" "svg"
    }

    ...
}

The public PlantUML URL (https://plantuml.com/plantuml) may work, but please be aware that you are sending information to a third-party service.
